GK01000010
2 way ball valve DN80 - 3" inch GK01 female thread
Delivery time: in stock
Express delivery*:
Shipping on: Thursday, 31. October
Guaranteed delivery until Friday, 01. November, 12 o'clock
Order in within by express delivery
Questions about the article?
Our employee Max Eisele
will be happy to help you
2 way ball valve DN80 - 3" inch full port design seal made of PTFE for liquid and gaseous media
| product: | 2 way ball valve |
|---|---|
| type: | GK01 |
| manufacturer: | NieRuf |
| diameter: | DN80 - 3" inch |
| connection: | female thread |
| Seal steam: | PTFE |
| ball seal: | PTFE |
| media: | liquid and gaseous media |
| temperature: | -20°C up to +180°C - depending on working pressure and media |
| max. pressure: | PN20 |
| design: | full port design |
| body material: | brass nickel plated (CW617N) |
| ball material: | brass chrome plated (CW614N) |
| length: | 167mm |
| actuator: | lever handle made of Aluminium, painted red |
| installation position: | any position |
| product description: | strength of valve body and cap acc. to EN 331 |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
2 way ball valve DN80 - 3" inch GK01 female thread
Article no.
: GK01000010
product:
2 way ball valve
type:
GK01
manufacturer:
NieRuf
diameter:
DN80 - 3" inch
connection:
female thread
Seal steam:
PTFE
ball seal:
PTFE
media:
liquid and gaseous media
temperature:
-20°C up to +180°C - depending on working pressure and media
max. pressure:
PN20
design:
full port design
body material:
brass nickel plated (CW617N)
ball material:
brass chrome plated (CW614N)
length:
167mm
actuator:
lever handle made of Aluminium, painted red
installation position:
any position
product description:
strength of valve body and cap acc. to EN 331
