FL01010111
Flange DN100 PN10/16 EN1092-1 11 B1 1.4571
Delivery time: 3 - 5 working days
Equipment
joint set flange/flange DN100 - 4" Inch for flange PN10/16/25 stainless steel
€19.99 VAT included.
Questions about the article?
Our employee Max Eisele
will be happy to help you
high quality Flange DN100 flange acc. DIN PN10/16 EN1092-1 Typ 11 B1 made of stainless steel 1.4571
| product: | Flange |
|---|---|
| type: | FL01 |
| manufacturer: | NieRuf |
| diameter: | DN100 |
| connection: | PN10/16 |
| material: | stainless steel |
| material nr.: | 1.4571 |
| norm: | EN1092-1 |
| norm-type: | 11 |
| surface: | B1 |
| Design: | Welding neck flange |
| Ø A: | 114,3 |
| D: | 220 |
| C2: | 20 |
| K: | 180 |
| H2: | 52 |
| N1: | 131 |
| S: | 3,6 |
| R1: | 8 |
| d1: | 158 |
| f1: | 3 |
| screw: | M16 |
| Qty. Screws: | 8 |
| L: | 18 |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
Flange DN100 PN10/16 EN1092-1 11 B1 1.4571
Article no.
: FL01010111
product:
Flange
type:
FL01
manufacturer:
NieRuf
diameter:
DN100
connection:
PN10/16
material:
stainless steel
material nr.:
1.4571
norm:
EN1092-1
norm-type:
11
surface:
B1
Design:
Welding neck flange
Ø A:
114,3
D:
220
C2:
20
K:
180
H2:
52
N1:
131
S:
3,6
R1:
8
d1:
158
f1:
3
screw:
M16
Qty. Screws:
8
L:
18
€5.36 VAT included.
€9.04 VAT included.
€19.99 VAT included.
€105.43 VAT included.
€62.59 VAT included.
€173.50 VAT included.
€102.94 VAT included.
