UV12030008
flange overflow valve DN 50 PN40 UV12 stainless steel AISI 316L 5,5 - 10,0 bar
Delivery time: 3 - 5 working days
Equipment
pressure gauge 0 - 16,0 bar G 1/4" axial 50 mm stainless steel MM05
€101.27 VAT included.
joint set flange/flange DN50 - 2" Inch for flange PN10/16/25/40 stainless steel
€10.00 VAT included.
Questions about the article?
Our employee Max Eisele
will be happy to help you
flange overflow valve DN 50 PN40 type UV12 made of stainless steel AISI 316L pressure range 5,5 - 10,0 bar seal FKM for liquid and gaseous media
| product: | flange overflow valve |
|---|---|
| type: | UV12 |
| manufacturer: | NieRuf |
| diameter: | DN 50 PN40 |
| connection: | flange acc. DIN EN 1092 |
| seal: | FKM |
| media: | liquid and gaseous media |
| temperature: | -10°C to +95°C |
| range of adjustment: | 5,5 - 10,0 bar |
| design: | straightway form |
| material: | stainless steel AISI 316L |
| installation position: | any position |
| SIL - safety integrity level: | SIL 2 |
| product feature: | High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
flange overflow valve DN 50 PN40 UV12 stainless steel AISI 316L 5,5 - 10,0 bar
Article no.
: UV12030008
product:
flange overflow valve
type:
UV12
manufacturer:
NieRuf
diameter:
DN 50 PN40
connection:
flange acc. DIN EN 1092
seal:
FKM
media:
liquid and gaseous media
temperature:
-10°C to +95°C
range of adjustment:
5,5 - 10,0 bar
design:
straightway form
material:
stainless steel AISI 316L
installation position:
any position
SIL - safety integrity level:
SIL 2
product feature:
High-quality, heat-resistant moulded elastomere, fabric-reinforced diaphragm. Valves in straightway form, closed version. Can be adjusted under operating conditions without medium escaping into the atmosphere.
