BE02001109
High pressure vessel horizontal BE02 1500 liter, 0-26 bar, steel galvanized
Delivery time: max. 11 weeks
Equipment
pressure gauge G 1/2" radial 100 mm stainless steel MM07 0 - 40,0 bar without filling, dry
€173.38 VAT included.
manometer gauge valves male thread x sleeve x test flange 60x25 mm DIN 16271 brass 250 bar
€50.22 VAT included.
Questions about the article?
Our employee Max Eisele
will be happy to help you
High pressure vessel BE02 with 1500 liter volume horizontal with operating pressure 0-26 bar made of steel galvanized and nominal size 1000 mm
| product: | High pressure vessel |
|---|---|
| type: | BE02 |
| manufacturer: | NieRuf |
| volume: | 1500 liter |
| nominal size: | 1000 mm |
| height: | 1200 mm |
| length: | 2070 mm |
| operating pressure: | 0-26 bar |
| version: | horizontal |
| temperature: | -10°C up to +50°C |
| material: | steel galvanized |
| media: | compressed air and nitrogen |
| product feature: | Longitudinal seams welded on both sides for safety with high pressure fluctuations, 1000 start-up & shut-downs and 20% pressure fluctuation range |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
High pressure vessel horizontal BE02 1500 liter, 0-26 bar, steel galvanized
Article no.
: BE02001109
product:
High pressure vessel
type:
BE02
manufacturer:
NieRuf
volume:
1500 liter
nominal size:
1000 mm
height:
1200 mm
length:
2070 mm
operating pressure:
0-26 bar
version:
horizontal
temperature:
-10°C up to +50°C
material:
steel galvanized
media:
compressed air and nitrogen
product feature:
Longitudinal seams welded on both sides for safety with high pressure fluctuations, 1000 start-up & shut-downs and 20% pressure fluctuation range
