PR01000000
Position indicator Typ PR01 for pneumatic actuator
Delivery time: in stock
Express delivery:
Shipping on: Monday, 23. December
Guaranteed delivery until Tuesday, 24. December, 12 o'clock
Order in within by express delivery
Questions about the article?
Our employee Max Eisele
will be happy to help you
Position indicator made of Polaymid for ball valves with pneumatic actuator, 2D position indicator 0...90° with signal open + closed
| product: | Position indicator |
|---|---|
| type: | PR01 |
| manufacturer: | NieRuf |
| Housing material: | Polyamid PA6 black |
| axis: | Polaymid PA6 |
| seal: | TPE+NBR |
| temperature: | -25°C to +80°C |
| voltage: | 24V / DC max. 2,5A | 250V / AC max. 10A |
| protection: | IP67 VDE 0470 / EN 60529 |
| indication: | 2D position indicator 0...90° |
| Electrical design: | mechanical micro switches ZF, D44X |
| signal: | open + closed |
| Actuator hole spacings: | 80 x 30mm |
| mounting measurements: | Cable gland M20x1,5, clamp range 6-12mm |
| product feature: | Compact limit switch box for direct mounting on actuators with hole pattern 80x30 mm |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
Position indicator Typ PR01 for pneumatic actuator
Article no.
: PR01000000
product:
Position indicator
type:
PR01
manufacturer:
NieRuf
Housing material:
Polyamid PA6 black
axis:
Polaymid PA6
seal:
TPE+NBR
temperature:
-25°C to +80°C
voltage:
24V / DC max. 2,5A | 250V / AC max. 10A
protection:
IP67 VDE 0470 / EN 60529
indication:
2D position indicator 0...90°
Electrical design:
mechanical micro switches ZF, D44X
signal:
open + closed
Actuator hole spacings:
80 x 30mm
mounting measurements:
Cable gland M20x1,5, clamp range 6-12mm
product feature:
Compact limit switch box for direct mounting on actuators with hole pattern 80x30 mm
€84.25 VAT included.
€326.06 VAT included.
