Product number: MV07110003
Solenoid valve G 1/2" Inch brass MV07 EPDM 230V 50Hz

2/2 Ways Solenoid valve G 1/2" Inch DN10 made of brass seal EPDM force pilot operated nominal voltage 230V 50Hz pressure 0.0 - 20 bar

product: Solenoid valve
type: MV07
manufacturer: NieRuf
design: seat valve with membrane
diameter: DN10
connection: G 1/2" Inch
type of connection: female thread
Type of design: 2/2 Ways
flow rate: 2.0 m³/h
function: NC - normally closed
control: force pilot operated
material: brass
seal: EPDM
voltage: 230V 50Hz
voltage tolerance: +/- 10% acc. VDE 0580
power consumption: 22 VA
duty: 100% ED
plug socket: IP65 with plug socket mounted
media: liquid and gaseous media
temperature media: -10°C up to +130°C
temperature ambiente: max up to +50°C
max. pressure: 0.0 - 20 bar
installation position: any position, solenoid preferably standing

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

Solenoid valve G 1/2" Inch brass MV07 EPDM 230V 50Hz

Article no. : MV07110003
product: Solenoid valve
type: MV07
manufacturer: NieRuf
design: seat valve with membrane
diameter: DN10
connection: G 1/2" Inch
type of connection: female thread
Type of design: 2/2 Ways
flow rate: 2.0 m³/h
function: NC - normally closed
control: force pilot operated
material: brass
seal: EPDM
voltage: 230V 50Hz
voltage tolerance: +/- 10% acc. VDE 0580
power consumption: 22 VA
duty: 100% ED
plug socket: IP65 with plug socket mounted
media: liquid and gaseous media
temperature media: -10°C up to +130°C
temperature ambiente: max up to +50°C
max. pressure: 0.0 - 20 bar
installation position: any position, solenoid preferably standing
