ZR02000309
swing check valve DN65 ZR02 stainless steel A351 CF8M PTFE
Delivery time: in stock
Express delivery*:
Shipping on: Friday, 22. November
Guaranteed delivery until Monday, 25. November, 12 o'clock
Order in within by express delivery
Equipment
joint set swing check valve/flange DN65 - 2 1/2" Inch for flange PN10/16 stainless steel
€10.95 VAT included.
Questions about the article?
Our employee Max Eisele
will be happy to help you
swing check valve DN65 PN 10/16/25/40 DIN EN 1092-1 Form B made of stainless steel A351 CF8M seal PTFE for liquid and gaseous media
| product: | swing check valve |
|---|---|
| type: | ZR02 |
| manufacturer: | NieRuf |
| design: | swing check valve |
| diameter: | DN65 |
| body material: | stainless steel A351 CF8M |
| disc material: | stainless steel A351 CF8M |
| seal: | PTFE |
| temperature: | -196°C up to +250°C |
| connection: | flange |
| flange: | PN 10/16/25/40 DIN EN 1092-1 Form B |
| pressure range: | 0 - 30 bar |
| media: | liquid and gaseous media |
| tightness acc. to DIN EN 12266: | leak rate A |
| option: | without spring reset |
| installation position: | direction of flow horizontal (disc must be free-hanging), vertical from below |
| product feature: | short face to face |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
swing check valve DN65 ZR02 stainless steel A351 CF8M PTFE
Article no.
: ZR02000309
product:
swing check valve
type:
ZR02
manufacturer:
NieRuf
design:
swing check valve
diameter:
DN65
body material:
stainless steel A351 CF8M
disc material:
stainless steel A351 CF8M
seal:
PTFE
temperature:
-196°C up to +250°C
connection:
flange
flange:
PN 10/16/25/40 DIN EN 1092-1 Form B
pressure range:
0 - 30 bar
media:
liquid and gaseous media
tightness acc. to DIN EN 12266:
leak rate A
option:
without spring reset
installation position:
direction of flow horizontal (disc must be free-hanging), vertical from below
product feature:
short face to face
€62.71 VAT included.
€75.57 VAT included.
€4.28 VAT included.
€10.95 VAT included.
€30.82 VAT included.
€79.61 VAT included.
There for you
Special requests, spare parts or a quick support? Our staff will answer your questions and concerns immediately.
You can reach us from Monday to Friday at +497143 9666900 and any time at sales@nieruf.com
Quality
Our certified quality management according to DIN EN ISO 9001: 2015 is part of our DNA. With our test stands we can carry out pressure tests with up to 350 bar with air and water as well as leak tests according to DIN EN 122661.
