SV03000205
angle-type safety valve 1" x 1 1/2" fm SV03 neutral liquid media, gunmetal FKM
- Delivery time
- 3 - 5 working days
Equipment
Certificates
Questions about the article?
safety-valve for neutral liquid media gunmetal 1" x 1 1/2" fm female thread FKM Typ SV03 with twist-type lifting mechanism without bellows
| product | angle-type safety valve |
|---|---|
| type | SV03 |
| manufacturer | NieRuf |
| diameter | 1" x 1 1/2" fm |
| d0 | 23,0 mm |
| connection | Female screw threaded BSP-P |
| seal | FKM |
| media | neutral liquid media |
| temperature | -20°C up to +200°C |
| set pressure | 0,5 - 25,0 bar- higher pressures possible in PTFE version |
| design | angle-type |
| material | gunmetal |
| lifting | twist-type lifting mechanism |
| type test approval | TÜV = F 666 / EG = L |
| requirements | acc. EN ISO 4126-1, VdTÜV-leaflet 100, AD2000-A2 |
| installation position | Safety valves with spring to be installed vertical with spring bonnet upwards standing. |
| SIL - safety integrity level | SIL 3 |
| product feature 1 | without bellows |
| product feature 2 | for neutral media without counter pressure. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
angle-type safety valve 1" x 1 1/2" fm SV03 neutral liquid media, gunmetal FKM
Article no.
: SV03000205
product:
angle-type safety valve
type:
SV03
manufacturer:
NieRuf
diameter:
1" x 1 1/2" fm
d0:
23,0 mm
connection:
Female screw threaded BSP-P
seal:
FKM
media:
neutral liquid media
temperature:
-20°C up to +200°C
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
design:
angle-type
material:
gunmetal
lifting:
twist-type lifting mechanism
type test approval:
TÜV = F 666 / EG = L
requirements:
acc. EN ISO 4126-1, VdTÜV-leaflet 100, AD2000-A2
installation position:
Safety valves with spring to be installed vertical with spring bonnet upwards standing.
SIL - safety integrity level:
SIL 3
product feature 1:
without bellows
product feature 2:
for neutral media without counter pressure.
