PK07000009

automatic-flange stainless steel ball valve DN65 PK07 pneumatic actuator double acting

€628.80*

€748.27 VAT included.


Configure valve
Configure your automated valve for your specific application here.

Delivery time
in stock
Express delivery*

Order in within by express delivery

Shipping on: Tuesday, 11. March

Guaranteed delivery until Wednesday, 12. March, 12 o'clock

* Specified delivery times apply for Mon. - Fri. without consideration of public holidays.

Equipment

NA02010001

5/2 ways NAMUR-Solenoid valve G 1/4" Inch NA02 24V DC

€44.40*

€52.84 VAT included.


PR02000000

Position indicator PR02 mechanical micro switches ZF, D44X Polyamid PA6 black

€70.80*

€84.25 VAT included.


FD01000109

flange seal DN65 PN10/16/25/40 77x127x2 Klingersil C 4400

€3.90*

€4.64 VAT included.


VS01000109

joint set flange/flange DN65 - 2 1/2" Inch for flange PN10/16/25 stainless steel

€8.40*

€10.00 VAT included.


PS01000000

Positioner PS01 for pneumatic actuators double acting air volume less than 5 l

€711.90*

€847.16 VAT included.


×

Questions about the article?

Our employee <strong>Max Eisele</strong><br>will be happy to help you

Our employee Max Eisele
will be happy to help you

Tel: +49714396669-12

E-Mail: eisele@nieruf.com

NIERUF-SERVICE

NieRuf-Exchange

NieRuf-Exchange

24 months warranty

24 months warranty

Certified

Certified

Product number: PK07000009
automatic-flange stainless steel ball valve DN65 PK07 pneumatic actuator double acting

automatic-flange stainless steel ball valve DN65 stainless steel 1.4408 PK07 pneumatic actuator GD88 made of aluminium (mode of function: GD = double acting)

product automatic-flange stainless steel ball valve
type PK07
manufacturer NieRuf
diameter DN65 - 2 1/2" inch
connection flange dimensions acc. DIN EN 1092-1 PN 16
Seal steam PTFE
media liquid and gaseous media
temperature ball valve: -20°C up to +180°C (depending on working pressure and media) - pneumatic actuator: - 20°C bis + 80°C
max. pressure PN16
design automatic-flange ball valve with pneumatic actuator (double acting)
body material stainless steel 1.4408
ball material stainless steel 1.4408
ball seal PTFE + TFM
length 110mm
actuator pneumatic actuator GD083 made of aluminium (mode of function: GD = double acting)
actuator informations Control pressure rate from 6 bar up to 8 bar / filtered air acc. to DIN ISO 8573-1: 2010
authorized for TA Luft
product description This high quality automatic-stainless steel ball valves with pneumatic actuator (GD = double acting) with direct mounting of magnetic valves per Namur is also possible.

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

automatic-flange stainless steel ball valve DN65 PK07 pneumatic actuator double acting

Article no. : PK07000009
product: automatic-flange stainless steel ball valve
type: PK07
manufacturer: NieRuf
diameter: DN65 - 2 1/2" inch
connection: flange dimensions acc. DIN EN 1092-1 PN 16
Seal steam: PTFE
media: liquid and gaseous media
temperature: ball valve: -20°C up to +180°C (depending on working pressure and media) - pneumatic actuator: - 20°C bis + 80°C
max. pressure: PN16
design: automatic-flange ball valve with pneumatic actuator (double acting)
body material: stainless steel 1.4408
ball material: stainless steel 1.4408
ball seal: PTFE + TFM
length: 110mm
actuator: pneumatic actuator GD083 made of aluminium (mode of function: GD = double acting)
actuator informations: Control pressure rate from 6 bar up to 8 bar / filtered air acc. to DIN ISO 8573-1: 2010
authorized for: TA Luft
product description: This high quality automatic-stainless steel ball valves with pneumatic actuator (GD = double acting) with direct mounting of magnetic valves per Namur is also possible.
