FK05050004
high temperature flange ball valve FK05 DN20 PN16 made of stainless steel 1.4408 up to +300
- Delivery time
- 1 - 2 weeks
Questions about the article?
high temperature flange ball valve FK05 DN20 PN16 body stainless steel 1.4408 ball stainless steel 1.4408 seal Antimony-coal for liquid and gaseous media
| product | high temperature flange ball valve |
|---|---|
| type | FK05 |
| manufacturer | NieRuf |
| diameter | DN20 |
| connection | flange dimensions acc. to EN 1092-1 PN16 |
| Seal steam | Graphite |
| body seal | graphite |
| ball seal | Antimony-coal |
| media | liquid and gaseous media |
| temperature | -20°C up to +300°C - depending on media and dimension |
| max. pressure | PN16 |
| design | full port design |
| body material | stainless steel 1.4408 |
| ball material | stainless steel 1.4408 |
| length | DIN EN 558 R 27 |
| actuator | lever handle made of stainless steel |
| installation position | any position |
| authorized for | TA Luft |
| product description | This high quality ball valve is made of stainless steel and has a blow-out proof stem with graphite gasket and is suitable for liquid media up to 300°C. The body is two-piece with mounting flange according to DIN ISO 5211 and lever handle made of stainless steel. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
high temperature flange ball valve FK05 DN20 PN16 made of stainless steel 1.4408 up to +300
Article no.
: FK05050004
product:
high temperature flange ball valve
type:
FK05
manufacturer:
NieRuf
diameter:
DN20
connection:
flange dimensions acc. to EN 1092-1 PN16
Seal steam:
Graphite
body seal:
graphite
ball seal:
Antimony-coal
media:
liquid and gaseous media
temperature:
-20°C up to +300°C - depending on media and dimension
max. pressure:
PN16
design:
full port design
body material:
stainless steel 1.4408
ball material:
stainless steel 1.4408
length:
DIN EN 558 R 27
actuator:
lever handle made of stainless steel
installation position:
any position
authorized for:
TA Luft
product description:
This high quality ball valve is made of stainless steel and has a blow-out proof stem with graphite gasket and is suitable for liquid media up to 300°C. The body is two-piece with mounting flange according to DIN ISO 5211 and lever handle made of stainless steel.
