MM05100801
pressure gauge 0 - 16,0 bar G 1/4" axial 50 mm stainless steel MM05
Delivery time: in stock
Express delivery*:
Shipping on: Friday, 21. November
Guaranteed delivery until Monday, 24. November, 12 o'clock
Order in within by express delivery
Questions about the article?
Our employee Max Eisele
will be happy to help you
pressure gauge 0 - 16,0 bar G 1/4" diameter: 50 mm stainless steel thread: external thread on backside made of stainless steel
| product: | pressure gauge |
|---|---|
| type: | MM05 |
| manufacturer: | NieRuf |
| diameter: | G 1/4" |
| connection: | external thread on backside |
| design: | axial |
| media: | gaseous, liquid, not highly viscous and crystallising media |
| temperature: | -20°C - +80°C |
| Measuring range: | 0 - 16,0 bar |
| Measuring range in: | bar |
| accuracy: | 1,6% |
| diameter viewing window: | 50 mm |
| filling: | without filling, dry |
| body material: | stainless steel |
| viewing window: | polycarbonate |
| material connection: | stainless steel |
| product feature: | Pressure gauge with pipe-spring measuring element made of stainless steel. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
pressure gauge 0 - 16,0 bar G 1/4" axial 50 mm stainless steel MM05
Article no.
: MM05100801
product:
pressure gauge
type:
MM05
manufacturer:
NieRuf
diameter:
G 1/4"
connection:
external thread on backside
design:
axial
media:
gaseous, liquid, not highly viscous and crystallising media
temperature:
-20°C - +80°C
Measuring range:
0 - 16,0 bar
Measuring range in:
bar
accuracy:
1,6%
diameter viewing window:
50 mm
filling:
without filling, dry
body material:
stainless steel
viewing window:
polycarbonate
material connection:
stainless steel
product feature:
Pressure gauge with pipe-spring measuring element made of stainless steel.
