SV03010208
safety valve 2" m x 2" fm SV03 neutral liquid media, gunmetal FKM
Delivery time: 3 - 5 working days
Certificates
Questions about the article?
Our employee Max Eisele
will be happy to help you
angle-type-safety-valve for liquid and gaseous media male thread 2" m x 2" fm gunmetal FKM Typ SV03 with twist-type lifting mechanism without bellows
| product: | safety valve |
|---|---|
| type: | SV03 |
| manufacturer: | NieRuf |
| diameter: | 2" m x 2" fm |
| d0: | 30,3 mm |
| connection: | male screw threaded BSP-P |
| seal: | FKM |
| media: | neutral liquid media |
| temperature: | -20°C up to +200°C |
| set pressure: | 0,5 - 25,0 bar- higher pressures possible in PTFE version |
| design: | angle-type |
| material: | gunmetal |
| lifting: | twist-type lifting mechanism |
| type test approval: | TÜV = F 666 / EG = L |
| requirements: | acc. EN ISO 4126-1, VdTÜV-leaflet 100, AD2000-A2 |
| installation position: | Safety valves with spring to be installed vertical with spring bonnet upwards standing. |
| SIL - safety integrity level: | SIL 3 |
| product feature 1: | without bellows |
| product feature 2: | for neutral media without counter pressure. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
safety valve 2" m x 2" fm SV03 neutral liquid media, gunmetal FKM
Article no.
: SV03010208
product:
safety valve
type:
SV03
manufacturer:
NieRuf
diameter:
2" m x 2" fm
d0:
30,3 mm
connection:
male screw threaded BSP-P
seal:
FKM
media:
neutral liquid media
temperature:
-20°C up to +200°C
set pressure:
0,5 - 25,0 bar- higher pressures possible in PTFE version
design:
angle-type
material:
gunmetal
lifting:
twist-type lifting mechanism
type test approval:
TÜV = F 666 / EG = L
requirements:
acc. EN ISO 4126-1, VdTÜV-leaflet 100, AD2000-A2
installation position:
Safety valves with spring to be installed vertical with spring bonnet upwards standing.
SIL - safety integrity level:
SIL 3
product feature 1:
without bellows
product feature 2:
for neutral media without counter pressure.
€23.21 VAT included.
€17.37 VAT included.
€55.22 VAT included.
€29.99 VAT included.
