KV05010002

solenoid valve input: 6mm plug 24V DC KV05

€46.50*

€55.34 VAT included.

Delivery time: in stock

Delivery information

Express delivery*:

Shipping on: Friday, 22. November

Guaranteed delivery until Monday, 25. November, 12 o'clock

Order in within by express delivery

* Specified delivery times apply for Mon. - Fri. without consideration of public holidays.

×
Our employee <strong>Max Eisele</strong><br>will be happy to help you

Questions about the article?

Our employee Max Eisele
will be happy to help you

Tel: +49714396669-12

E-Mail: eisele@nieruf.com

24 months warranty

24 months warranty

Product number: KV05010002
solenoid valve input: 6mm plug 24V DC KV05

3/2-solenoid valve output: G 1/8" Inch input: 6mm plug plastic polyamid 24V DC NC - normally closed direct acting pressure air -0,9 - 10 bar

product: Solenoid valve
type: KV05
manufacturer: NieRuf
design: directly controlled three port solenoid valve with two outputs
diameter: DN6
connection: output: G 1/8" Inch
connection 2: input: 6mm plug
type of connection: male thread
Type of design: 3/2 ways
flow rate: 50 l/min
function: NC - normally closed
control: direct acting
material: plastic polyamid
voltage: 24V DC
power consumption: 3 Watt
media: pressure air
max. pressure: -0,9 - 10 bar
installation position: any position, solenoid valve preferably upwards

Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.

solenoid valve input: 6mm plug 24V DC KV05

Article no. : KV05010002
product: Solenoid valve
type: KV05
manufacturer: NieRuf
design: directly controlled three port solenoid valve with two outputs
diameter: DN6
connection: output: G 1/8" Inch
connection 2: input: 6mm plug
type of connection: male thread
Type of design: 3/2 ways
flow rate: 50 l/min
function: NC - normally closed
control: direct acting
material: plastic polyamid
voltage: 24V DC
power consumption: 3 Watt
media: pressure air
max. pressure: -0,9 - 10 bar
installation position: any position, solenoid valve preferably upwards

No spare parts were found for the item number .
