KA01000001
steam trap Bekomat 31U compressor performance 2,5 m3/min
Delivery time: 3 - 5 working days
Questions about the article?
Our employee Max Eisele
will be happy to help you
steam trap Bekomat 31U with compressor performance 2,5 m3/min, operating pressure 0,8 - 16,0 bar and seal FKM, inlet G 1/2 inch & discharge G 1/4 inch
| product: | steam trap |
|---|---|
| type: | Bekomat 31U |
| manufacturer: | NieRuf |
| condensate inlet: | 1 x G 1/2" inch (inside) |
| condensate discharge: | 1 x G 1/4" inch, hose connector, hose Ø=10 mm (inside) |
| material: | Plastic & aluminium |
| operating pressure: | 0,8 - 16,0 bar |
| seal: | FKM |
| ambient temperature: | +1°C - +60°C |
| compressor performance: | 2,5 m3/min (Central- und Southern Europe, Central America) |
| refrigeration dryer performance: | 5 m3/min (Central- und Southern Europe, Central America) |
| filter performance: | 30 m3/min (Central- und Southern Europe, Central America) |
| power consumption: | 0,6 - 3 VA (W) |
| protection class: | IP 67 |
| voltage: | 95-240V AC (50-60 Hz) / 100-125 VDC |
| media: | oil-based or oil-free condensate |
| application: | for pressure vessels BE01 from 50 to 750 l |
| product feature: | Automatic start of self-cleaning process based on dirt particle load. No loss of compressed air during draining. Outstanding reliability. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
steam trap Bekomat 31U compressor performance 2,5 m3/min
Article no.
: KA01000001
product:
steam trap
type:
Bekomat 31U
manufacturer:
NieRuf
condensate inlet:
1 x G 1/2" inch (inside)
condensate discharge:
1 x G 1/4" inch, hose connector, hose Ø=10 mm (inside)
material:
Plastic & aluminium
operating pressure:
0,8 - 16,0 bar
seal:
FKM
ambient temperature:
+1°C - +60°C
compressor performance:
2,5 m3/min (Central- und Southern Europe, Central America)
refrigeration dryer performance:
5 m3/min (Central- und Southern Europe, Central America)
filter performance:
30 m3/min (Central- und Southern Europe, Central America)
power consumption:
0,6 - 3 VA (W)
protection class:
IP 67
voltage:
95-240V AC (50-60 Hz) / 100-125 VDC
media:
oil-based or oil-free condensate
application:
for pressure vessels BE01 from 50 to 750 l
product feature:
Automatic start of self-cleaning process based on dirt particle load. No loss of compressed air during draining. Outstanding reliability.
