SZ04000014
strainer DN200 PN16 type SZ04 cast iron GG25
Delivery time: 3 - 5 working days
Equipment
joint set flange/flange DN200 - 8" Inch for flange PN16 steel
€41.41 VAT included.
Questions about the article?
Our employee Max Eisele
will be happy to help you
strainer made of cast iron GG25 epoxyd painting DN200 flange PN16 with EPDM-seal for water from -10°C up to +80°C
| product: | strainer |
|---|---|
| type: | SZ04 |
| manufacturer: | NieRuf |
| design: | Y-strainer with draining cap |
| diameter: | DN200 |
| connection: | flange |
| pressure: | PN16 |
| material: | cast iron GG25 epoxyd painting |
| mesh-material: | stainless steel 1.4301 |
| cap material: | stainless steel 1.4310 |
| seal: | EPDM |
| media: | water, drinking water |
| temperature: | -10°C up to +80°C |
| norm: | Directive 2014/68/EU: product excluded from directive (article 4, § 3) |
| mesh: | 2 mm |
| installation position: | horizontal or vertical position with descendant fluid |
| product feature: | Y-strainer flange made of cast iron with draining cap and removable stainless steel filter, horizontal or vertical position. |
Quickly and easily transfer the specification of our valves to your tender text or specification of services.
Simply copy the text field below and paste it into your tender.
strainer DN200 PN16 type SZ04 cast iron GG25
Article no.
: SZ04000014
product:
strainer
type:
SZ04
manufacturer:
NieRuf
design:
Y-strainer with draining cap
diameter:
DN200
connection:
flange
pressure:
PN16
material:
cast iron GG25 epoxyd painting
mesh-material:
stainless steel 1.4301
cap material:
stainless steel 1.4310
seal:
EPDM
media:
water, drinking water
temperature:
-10°C up to +80°C
norm:
Directive 2014/68/EU: product excluded from directive (article 4, § 3)
mesh:
2 mm
installation position:
horizontal or vertical position with descendant fluid
product feature:
Y-strainer flange made of cast iron with draining cap and removable stainless steel filter, horizontal or vertical position.
€25.35 VAT included.
€41.41 VAT included.
€366.52 VAT included.
€503.49 VAT included.
